Product Introduction：HIGH THERMAL AND DIELECTRIC PERFORMANCE INSULATOR PAD
PRODUCT DESCRIPTION
FEATURES AND BENEFITS
SPECIFICATIONS
TDS Download
Tgard™ K52 is a high thermal and dielectric performance insulator pad consisting of a ceramic filled phase change compound coated on MT Kapton film. Tgard™ K52 phase change coating all but eliminates contact thermal resistance. The phase change coating melts at 52ºC and replaces all contact areas that contain air. Tgard™ K52-1 is ideal for applications requiring the best thermal performing insulator material. Tgard™ K52-2 has the best balance of thermal, dielectric and cut through performance. Tgard™ K52-3 is a 3 mil MT Kapton film that provides the best crush and cut and tear resistance available with thermal properties that are still in the high performance category.
5.0 W/mK thermal conductivity
Low pressure versus deflection
Excellent surface wetting for low contact resistance
Minimizes board and component stress
Large tolerance applications
Environmentally friendly solution that meets regulatory requirements including RoHS and REACH
